HRC PRODUCT CATALOG

CIRCUIT BREAKER MOUNTING KITS

CUTLER HAMMER / WESTINGHOUSE

SEARCH The Catalog

Cutler Hammer PRL4A Boards / Challenger PM4 Boards

OEM#	TYPE	BREAKER	HRC KIT #	MAX AMPS	DIAGRAM	PIC	PRICE
KPRL4FD	TWIN	EHD,FDB	21-A131FD4	150	View \| download		Request A Quote
KPRL4FD-2C	TWIN	2 COVERS FD, EHB	21-A131FFD4	150	View \| download		Request A Quote
KPRL4ED	TWIN	FD,HFD,ED,EDH	21-A141ED4	225	View \| download		Request A Quote
KPRL4CA	TWIN	CA,CAH,HCA	21-A141CA4	225	View \| download		Request A Quote
KPRL4JDS	SINGLE	JD,HJD	21-A151JD1	250	View \| download		Request A Quote
KPRL4JDT	TWIN	JD,HJD	21-A151JD4	250	View \| download		Request A Quote
KPRL4KDS	SINGLE	DK,(H)KD	21-A161KD1	400	View \| download		Request A Quote
KPRL4KDT	TWIN	DK,(H)KD	21-A161KD4	400	View \| download		Request A Quote
KPRL4LG	SINGLE	LG	21-A171LG1	600	View \| download		Request A Quote
KPRL4LD	SINGLE	(H)LD	21-A171LD4	600	View \| download		Request A Quote
KPRL4MD	SINGLE	(H)MDL,MA,MC	21-A181MD4	800	View \| download		Request A Quote
KPRL4ND	SINGLE	(H)ND,NB,NC	21-A191ND4	1200	View \| download		Request A Quote

Cutler Hammer PRL4(B) Boards (narrow boards)

OEM#	TYPE	BREAKER	HRC KIT #	MAX AMPS	DIAGRAM	PIC	PRICE
KPRL4FD	TWIN	EHD,FDB	21-A13FFD4	150	View \| download		Request A Quote
KPRL4ED	TWIN	(H)FD,ED,EDH	21-A14FED4	225	View \| download		Request A Quote
KPRL4CA	TWIN	CA, CAH, HCA	21-A14FCA4	225	View \| download		Request A Quote
KPRL4JDS	SINGLE	(H)JD	21-A15FJD1	250	View \| download		Request A Quote
KPRL4KDS	SINGLE	DK,(H)KD	21-A16FKD1	400	View \| download		Request A Quote
KPRL4LD	SINGLE	(H)LD	21-A17FLD4	600	View \| download		Request A Quote

Cutler Hammer PRL3A Boards

OEM#	TYPE	BREAKER	HRC KIT #	MAX AMPS	DIAGRAM	PIC	PRICE
KPRL3AFD3	TWIN	ED, EDB, EDH, EHD, FD, FDB, FDC, HFD HMCP, E2F, FWF	21-A23EFD4	150	View \| download		Request A Quote

Westinghouse CDP/FDP Boards

OEM#	TYPE	BREAKER	HRC KIT #	MAX AMPS	DIAGRAM	PIC	PRICE
KCDPFB	TWIN	EB,EHB,(H)FB	21-A132FB1	150	View \| download		Request A Quote
KCDPED	TWIN	ED,(H)FD	21-A142FD1	225	View \| download		Request A Quote
KCDPCA	TWIN	CA,CAH,HCA	21-A142CA1	225	View \| download		Request A Quote
KCDPKB	TWIN	JB,(H)KB	21-A152KB1	250	View \| download		Request A Quote
KCDPLB	TWIN	DA,(H)KA,(H)LB	21-A162LB1	400	View \| download		Request A Quote
KCDPKD	TWIN	(H)KD	21-A162KD1	400	View \| download		Request A Quote
KCDPLA4	TWIN	(H)LA,(H)LC	21-A162LA4	400	View \| download		Request A Quote
KCDPLA6	TWIN	(H)LA,(H)LC	21-A172LA6	600	View \| download		Request A Quote
KCDPLD6	TWIN	(H)LD	21-A172LD3	600	View \| download		Request A Quote
KCDPMA	SINGLE	(H)MA,(H)MC	21-A182MD1	800	View \| download		Request A Quote
KCDPNB	SINGLE	(H)NB,(H)NC	21-A192ND1	1200	View \| download		Request A Quote

FEDERAL PACIFIC

SEARCH The Catalog

Federal Pacific BDP/FDP(DOUBLE HOLE VERTICAL BUS)

OEM#	TYPE	BREAKER	HRC KIT #	MAX AMPS	DIAGRAM	PIC	PRICE
KBDP1	TWIN	NE,NEF,NEG,HEF,HEG	21-C115NEF	100	View \| download		Request A Quote
KBDP2	TWIN	NEJ,HEJ	21-C145NEJ	225	View \| download		Request A Quote
KBDP3	TWIN	NFJ,HFJ	21-C145NFJ	225	View \| download		Request A Quote
KBDP4	TWIN	NJL,HJL	21-C165NJL	400	View \| download		Request A Quote

Federal Pacific CDP (SINGLE HOLE VERTICAL BUS)

OEM#	TYPE	BREAKER	HRC KIT #	MAX AMPS	DIAGRAM	PIC	PRICE
KCDP1	TWIN	NE,NEF,NEG,HEF,HEG	21-C112NEF	100	View \| download		Request A Quote
KCDP2	TWIN	NEJ,HEJ	21-C142NEJ	225	View \| download		Request A Quote
KCDP3	TWIN	NFJ,HFJ	21-C142NFJ	225	View \| download		Request A Quote
KCDP4	TWIN	NJL,HJL	21-C162NJL	400	View \| download		Request A Quote

GENERAL ELECTRIC

SEARCH The Catalog

General Electric APNB Spectra Series Bolt On Boards

OEM#	TYPE	BREAKER	HRC KIT #	MAX AMPS	DIAGRAM	PIC	PRICE
AMCB6EYFB	TWIN	TEY	21-D117TEY	100	View \| download		Request A Quote
AMCB6EBFP	TWIN	TEB,TED,SE	21-D137SED	150	View \| download		Request A Quote
AMCB6QDFP	TWIN	TQD,THQD	21-D147TQD	25	View \| download		Request A Quote
AMCB6FPFJ	TWIN	SFDA/HA/LA/PA	21-D157SFH	250	View \| download		Request A Quote
AMCB3FJFP	SINGLE	SFDA/HA/LA/PA	21-D157SFL	250	View \| download		Request A Quote
AMCB6GBFP	TWIN	SGDA/HA/LA/PA	21-D177SGD	600	View \| download		Request A Quote
AMCB3GMFP	SINGLE	SGDA/HA/LA/PA	21-D177SGH	600	View \| download		Request A Quote
AMCB3KMFP	SINGLE	SKHA/LA/PA	21-D197SKH	1200	View \| download		Request A Quote

General Electric AV1,AV2.CCB

OEM#	TYPE	BREAKER	HRC KIT #	MAX AMPS	DIAGRAM	PIC	PRICE
TED1DPK	TWIN	TEB,TED,THED	21-D136TED	150	View \| download		Request A Quote
TQ2DPK	TWIN	TQD,THQD	21-D146TQD	225	View \| download		Request A Quote
TF2DPK	TWIN	TFJ,TFK,THFK	21-D156TFK	250	View \| download		Request A Quote
TJ4DPK	TWIN	TJD,TJJ,TJK,THJK	21-D166TJK	400	View \| download		Request A Quote
TJ6DPK	TWIN	TJK,THJK	21-D176TJK	600	View \| download		Request A Quote
SG6DPK	TWIN	SGDA/HA/LA/PA	21-D176SGD	600	View \| download		Request A Quote
TB8SPK	SINGLE	TB6,TB8	21-D186TB8	800	View \| download		Request A Quote
TK6SPK	SINGLE	TKMA,THKM,SK	21-D186SKL	800	View \| download		Request A Quote
TK12SPK	SINGLE	TKMA,THKM,SK	21-D196TKM	1200	View \| download		Request A Quote

SIEMENS / I.T.E.

SEARCH The Catalog

ITE/Siemens FCI/II,FC20,CDP5/6,VB6,S5,P5,SPP,FPP,SB1/2/3(12 3/4"DEEP)

>

OEM#	TYPE	BREAKER	HRC KIT #	MAX AMPS	DIAGRAM	PIC	PRICE
6E62,SE6D	TWIN	ED,HED	21-B123ED6	125	View \| download		Request A Quote
6QJ2,SQJD	TWIN	QJ,QJH	21-B143QJ6	225	View \| download		Request A Quote
6F62,SF6D	TWIN	F(X)D,HF(X)D	21-B153FD6	250	View \| download		Request A Quote
6JJ62,SJ1D	TWIN	J(X)D,HJ(X)D	21-B163JD6	400	View \| download		Request A Quote
6LL61,SLD6	SINGLE	L(X)D,HL(X)D	21-B173LD6	600	View \| download		Request A Quote
SLM1D	SINGLE	LM(X)D,HLM(X)D	21-B183LM6	800	View \| download		Request A Quote
6M61,SMMD	SINGLE	M(X)D,HM(X)D	21-B183MD6	800	View \| download		Request A Quote
	NARROW	M(X)D,HM(X)D	21-B183MD6N	800	View \| download		Request A Quote
6N61,SMND	SINGLE	N(X)D,HN(X)D	21-B193ND6	1200	View \| download		Request A Quote
	NARROW	N(X)D,HN(X)D	21-B193ND6N	1200	View \| download		Request A Quote

ITE/Siemens S4,P4,SPP,FPP,F1 (10" DEEP)

OEM#	TYPE	BREAKER	HRC KIT #	MAX AMPS	DIAGRAM	PIC	PRICE
SE6	TWIN	ED,HED	21-B128SE6	125	View \| download		Request A Quote
SQJ	TWIN	QJ,QJH	21-B148SQJ	225	View \| download		Request A Quote
SF6	TWIN	F(X)D,HF(X)D	21-B158SF6	250	View \| download		Request A Quote
SJ1	SINGLE	J(X)D,HJ(X)D	21-B168SJ6	400	View \| download		Request A Quote
SL6	SINGLE	L(X)D,HL(X)D	21-B178SL6	600	View \| download		Request A Quote

ITE VB,FC20

OEM#	TYPE	BREAKER	HRC KIT #	MAX AMPS	DIAGRAM	PIC	PRICE
5EH2	TWIN	EE,EH,EF,HE	21-B134EH3	150	View \| download		Request A Quote
5FJ2	TWIN	FJ	21-B144FJ3	225	View \| download		Request A Quote
5JJ2	TWIN	JD,JJ,JL,HJ	21-B164JJ3	400	View \| download		Request A Quote
	TWIN	L(X)D,HL(X)D	21-B174LD6	600	View \| download		Request A Quote

PANEL MOUNTED SWITCH MOUNTING KITS

CUTLER HAMMER / WESTINGHOUSE

SEARCH The Catalog

Cutler Hammer / Westinghouse PRL4

OEM#	TYPE	SWITCH	HRC KIT #	MAX AMPS	DIAGRAM	PRICE
KPRL4W9X	SINGLE	FDPW325R/365R/365J	21-P161FDP4	400	View \| download	Request A Quote
KPRL4W11X	SINGLE	FDPW326/366/327/367	21-P181FDPW	600/800	View \| download	Request A Quote

Cutler Hammer / Westinghouse FDP

OEM#	TYPE	SWITCH	HRC KIT #	MAX AMPS	DIAGRAM	PRICE
CBA360FDP	SINGLE	FDPS326/366	21-P172FDPS	600	View \| download	Request A Quote

GENERAL ELECTRIC

SEARCH The Catalog

General Electric

OEM#	TYPE	SWITCH	HRC KIT #	MAX AMPS	DIAGRAM	PRICE
THFP63DPK	SINGLE	QMR/THFP 30-100A	21-S116QMR	100	View \| download	Request A Quote

FULL BLANK FILLER PLATES

CUTLER HAMMER / WESTINGHOUSE

SEARCH The Catalog

Cutler Hammer PRL4A Boards / Challenger PM4 Boards

OEM#	PLATE HEIGHT (Inches)	BOX WIDTH (Inches)	HRC KIT #	DIAGRAM	PRICE
655C02H01	1.375	36" 44"	21F-A1-01-CH	Call	Request A Quote
655C02H02	2.75	36" 44"	21F-A1-02-CH	Call	Request A Quote
655C02H03	4.125	36" 44"	21F-A1-03-CH	Call	Request A Quote
655C02H04	5.5	36" 44"	21F-A1-04-CH	Call	Request A Quote
655C02H05	6.875	36" 44"	21F-A1-05-CH	Call	Request A Quote
			21F-A1-06-CH	Call	Request A Quote

Cutler Hammer PRL4(B) Boards (narrow boards)

OEM#	PLATE HEIGHT (Inches)	BOX WIDTH (Inches)	HRC KIT #	DIAGRAM	PRICE
6554C01H01	1.375	24"	21F-AF-01-CHB	Call	Request A Quote
6554C01H02	2.75	24"	21F-AF-02-CHB	Call	Request A Quote
6554C01H03	4.125	24"	21F-AF-03-CHB	Call	Request A Quote

Westinghouse CDP/FDP Boards

OEM#	PLATE HEIGHT (Inches)	BOX WIDTH (Inches)	HRC KIT #	DIAGRAM	PRICE
KCDP1X	1.375	30" 38" 48"	21F-A2-01-W	Call	Request A Quote
KCDP2X	2.75	30" 38" 48"	21F-A2-02-W	Call	Request A Quote
KCDP3X	4.125	30" 38" 48"	21F-A2-03-W	Call	Request A Quote

GENERAL ELECTRIC

SEARCH The Catalog

General Electric APNB Spectra Series Bolt On Boards

OEM#	PLATE HEIGHT (Inches)	BOX WIDTH (Inches)	HRC KIT #	DIAGRAM	PRICE
APP1S/APP1	1.375	27"31"26"40"	21F-D7-01-GE	Call	Request A Quote
APP2S/APP2	2.75	27"31"26"40"	21F-D7-02-GE	Call	Request A Quote
APP3S/APP3	4.125	27"31"26"40"	21F-D7-03-GE	Call	Request A Quote
APP4S/APP4	5.5	27"31"26"40"	21F-D7-04-GE	Call	Request A Quote
APP5S/APP5	6.875	27"31"26"40"	21F-D7-05-GE	Call	Request A Quote

General Electric AV1,AV2,CCB

OEM#	PLATE HEIGHT (Inches)	BOX WIDTH (Inches)	HRC KIT #	DIAGRAM	PRICE
CCBFP1	1.375	31" 35" 40 "	21F-D6-01-GE	Call	Request A Quote
CCBFP2	2.75	31" 35" 40 "	21F-D6-02-GE	Call	Request A Quote
CCBFP3	4.125	31" 35" 40 "	21F-D6-03-GE	Call	Request A Quote
CCBFP4	5.5	31" 35" 40 "	21F-D6-04-GE	Call	Request A Quote
CCBFP5	6.875	31" 35" 40 "	21F-D6-05-GE	Call	Request A Quote

ITE / Siemens

SEARCH The Catalog

ITE/Siemens FCI/II,FC20,CDP5/6,VB6,S5,P5,SPP,FPP (12 3/4" DEEP)

S4,P4,SPP,FPP,F1 (10" DEEP)

OEM#	PLATE HEIGHT (Inches)	BOX WIDTH (Inches)	HRC KIT #	DIAGRAM	PRICE
6FBP01	1.25	32"(S4) 38"(S5)	21F-B3-01-S	Call	Request A Quote
6FBP02	2.5	32"(S4) 38"(S5)	21F-B3-02-S	Call	Request A Quote
6FBP03	3.75	32"(S4) 38"(S5)	21F-B3-03-S	Call	Request A Quote
6FBP05	5	32"(S4) 38"(S5)	21F-B3-04-S	Call	Request A Quote

EZCAN ENCLOSURES

ENCLOSURES

SEARCH The Catalog

250 AMP NEMA 1 and NEMA 3R

HRC CATALOG #	NEMA RATING	AMPS	HEIGHT (Inches)	WIDTH (Inches)	DEPTH (Inches)	PIC	PRICE
CBE12	NEMA 1	250	36"	12"	7"	View \| download	Request A Quote
CBE32	NEMA 3R	250	39"	12"	10.5"	View \| download	Request A Quote

600 AMP NEMA 1 and NEMA 3R

HRC CATALOG #	NEMA RATING	AMPS	HEIGHT (Inches)	WIDTH (Inches)	DEPTH (Inches)	PIC	PRICE
CBE16	NEMA 1	600	45"	18"	9"	View \| download	Request A Quote
CBE36	NEMA 3R	600	48"	18"	12.5"	View \| download	Request A Quote

1200 AMP NEMA 1 and NEMA 3R

HRC CATALOG #	NEMA RATING	AMPS	HEIGHT (Inches)	WIDTH (Inches)	DEPTH (Inches)	PIC	PRICE
CBE112	NEMA 1	1200	60"	21"	9"	View \| download	Request A Quote
CBE312	NEMA 3R	1200	63"	21"	12.5"	View \| download	Request A Quote

BREAKER HARWARE KITS FOR EZCAN ENCLOSURES

CUTLER-HAMMER

SEARCH The Catalog

250 AMP

HRC CATALOG #	NEMA RATING	MAX AMPS	MFG COMPATIBLE	DIAGRAM	PRICE
CBE12-CH-JD	NEMA 1	250	Cutler Hammer	Call	Request A Quote
CBE32-CH-JD	NEMA 3R	250	Cutler Hammer	Call	Request A Quote

600 AMP

HRC CATALOG #	NEMA RATING	MAX AMPS	MFG COMPATIBLE	DIAGRAM	PRICE
CBE16-CH-LD	NEMA 1	600	Cutler Hammer	Call	Request A Quote
CBE36-CH-LD	NEMA 3R	600	Cutler Hammer	Call	Request A Quote

1200 AMP

HRC CATALOG #	NEMA RATING	MAX AMPS	MFG COMPATIBLE	DIAGRAM	PRICE
CBEllZ-CH-ND	NEMA 1	1200	Cutler Hammer	Call	Request A Quote
CBE312-CH-ND	NEMA 3R	1200	Cutler Hammer	Call	Request A Quote

GENERAL ELECTRIC

SEARCH The Catalog

250 AMP

HRC CATALOG #	NEMA RATING	MAX AMPS	MFG COMPATIBLE	DIAGRAM	PRICE
CBE12-GE-SFL	NEMA 1	250	General Electric	Call	Request A Quote
CBE32-GE-SFL	NEMA 3R	250	General Electric	Call	Request A Quote

600 AMP

HRC CATALOG #	NEMA RATING	MAX AMPS	MFG COMPATIBLE	DIAGRAM	PRICE
CBE16-GE-SGL	NEMA 1	600	General Electric	Call	Request A Quote
CBE36-GE-SGL	NEMA 3R	600	General Electric	Call	Request A Quote

1200 AMP

HRC CATALOG #	NEMA RATING	MAX AMPS	MFG COMPATIBLE	DIAGRAM	PRICE
CBE112-GE-SKHA	NEMA 1	1200	General Electric	Call	Request A Quote
CBE312-GE-SKHA	NEMA 3R	1200	General Electric	Call	Request A Quote

SEIMENS

SEARCH The Catalog

250 AMP

HRC CATALOG #	NEMA RATING	MAX AMPS	MFG COMPATIBLE	DIAGRAM	PRICE
CBE12-SIE-FD6	NEMA 1	250	Siemens	Call	Request A Quote
CBE32-SIE-FD6	NEMA 3R	250	Siemens	Call	Request A Quote

600 AMP

HRC CATALOG #	NEMA RATING	MAX AMPS	MFG COMPATIBLE	DIAGRAM	PRICE
CBE16-SIE-LXD	NEMA 1	600	Siemens	Call	Request A Quote
CBE36-SIE-LXD	NEMA 3R	600	Siemens	Call	Request A Quote

1200 AMP

HRC CATALOG #	NEMA RATING	MAX AMPS	MFG COMPATIBLE	DIAGRAM	PRICE
CBE112-SIE-ND	NEMA 1	1200	Siemens	Call	Request A Quote
CBE312-SIE-ND	NEMA 3R	1200	Siemens	Call	Request A Quote

SQUARE D

SEARCH The Catalog

250 AMP

HRC CATALOG #	NEMA RATING	MAX AMPS	MFG COMPATIBLE	DIAGRAM	PRICE
CBE12-SQD-KAL	NEMA 1	250	Square D	Call	Request A Quote
CBE32-SQD-KAL	NEMA 3R	250	Square D	Call	Request A Quote

600 AMP

HRC CATALOG #	NEMA RATING	MAX AMPS	MFG COMPATIBLE	DIAGRAM	PRICE
CBE16-SQD-LCL	NEMA 1	600	Square D	Call	Request A Quote
CBE36-SQD-LCL	NEMA 3R	600	Square D	Call	Request A Quote

1200 AMP

HRC CATALOG #	NEMA RATING	MAX AMPS	MFG COMPATIBLE	DIAGRAM	PRICE
CBE112-SQD-MAMH	NEMA 1	1200	Square D	Call	Request A Quote
CBE312-SQD-MAMH	NEMA 3R	1200	Square D	Call	Request A Quote

BUS HARDWARE FOR EZCAN ENCLOSURES

BUS HARDWARE

SEARCH The Catalog

For EZCan Enclosures

>

HRC CATALOG #	AMPS	BUS TYPE	PIC	PRICE
CBE-02-GB	250	Ground Bus	Call	Request A Quote
CBE-02-NB	250	Neutral Bus	Call	Request A Quote
CBE-06-GB	600	Ground Bus	Call	Request A Quote
CBE-06-NB	600	Neutral Bus	Call	Request A Quote
CBE-012-GB	1200	Ground Bus	Call	Request A Quote
CBE-012-NB	1200	Neutral Bus	Call	Request A Quote
